Reducing Union
Most Prominent Reducing Union Pipe Fitting Manufacturer, Reducing Union Instrumentation Pipe Fitting, Reducing Union Connector, Reducing Union Stockist, Reducing Union Adapter, Reducing Union Tubing, Reducing Union with Ferrule Fittings Supplier
Stainless Steel Reducing Union Fittings Stockist, Carbon Steel Reducing Union Pipe Fittings, Nickel Alloy Reducing Union Fittings, Alloy Steel Reducing Union Pipes Fittings Exporter
Jaydeep Steels is the most trusted supplier, stockist, and exporter of a wide range of Reducing Union Pipe Fittings which are available in various dimensions, specifications, and forms. We manufacture these fittings as per the Indian as well as International Standards. After manufacturing these fittings goes under a variety of quality test.
Reducing Union is one of the types of ferrule fittings that are used to connect pipes or tubes of different diameters. The offered Reducing Union Fittings are fabricated using prime quality raw materials and modern industrial technology. Our fittings have high strength, high ductility, larger work life, excellent surface finish, and cost-effectiveness.
Reducing Union, Reducing Union Manufacturer, Reducing Union Exporters
SS 304 Reducing Union, SS 316 Reducing Union Fittings, Copper Nickel Union Fittings, Cu-Ni 90/10 Reducing Union Fittings Stockholder
The industrial fittings are offered according to international standards like ASME, JIS, AISI, IS, BS, DIN, etc. We supply these fittings in different grades of material alloys like Stainless Steel Pipe Fittings, Alloy Steel Pipe Fittings, Carbon Steel Pipe Fittings, and Nickel Alloy Pipe Fittings. These pipe fittings are used in various industries applications such as oil & gas, petrochemical, power generation, pharmaceuticals and more.
If you don’t find what you looking for or you want to buy these fittings then Contact Us today. Our industrial expert will guide you to choose the best product to build your application. We can assure you with the best buy price on products.
Technical Specification
| Part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT (INCHES) | D1 | Ø E | ODT-ØT1 (INCHES) | C | BODY HEX F | NUT HEX W | D | L | L1 | NUT HEX W1 | C1 |
| 2-RUD-1 | -200-6-1 | 2RU1 | 1/8 | 0.34 | 0.05 | 1/16 | 0.60 | 1.22 | 7/16 | 0.50 | 0.81 | 5/16 | 7/16 | 0.43 |
| 3-RUD-1 | -300-6-1 | 3RU1 | 3/16 | 0.34 | 0.05 | 1/16 | 0.63 | 1.27 | 7/16 | 0.54 | 0.86 | 5/16 | 7/16 | 0.43 |
| 3-RUD-2 | -300-6-2 | 3RU2 | 3/16 | 0.50 | 0.09 | 1/8 | 0.63 | 1.44 | 7/16 | 0.54 | 0.92 | 7/16 | 7/16 | 0.6 |
| 4-RUD-1 | -400-6-1 | 4RU1 | 1/4 | 0.34 | 0.05 | 1/16 | 0.70 | 1.35 | 7/16 | 0.60 | 0.91 | 5/16 | 9/16 | 0.43 |
| 4-RUD-2 | -400-6-2 | 4RU2 | 1/4 | 0.50 | 0.09 | 1/8 | 0.70 | 1.52 | 7/16 | 0.60 | 0.97 | 7/16 | 9/16 | 0.6 |
| 4-RUD-3 | -400-6-3 | 4RU3 | 1/4 | 0.54 | 0.12 | 3/16 | 0.70 | 1.55 | 7/16 | 0.60 | 1 | 1/2 | 9/16 | 0.63 |
| 5-RUD-2 | -500-6-2 | 5RU2 | 5/16 | 0.50 | 0.09 | 1/8 | 0.73 | 1.56 | 9/16 | 0.64 | 1.01 | 7/16 | 5/8 | 0.6 |
| 5-RUD-4 | -500-6-4 | 5RU4 | 5/16 | 0.60 | 0.19 | 1/4 | 0.73 | 1.66 | 9/16 | 0.64 | 1.08 | 9/16 | 5/8 | 0.7 |
| 6-RUD-1 | -600-6-1 | 6RU1 | 3/8 | 0.34 | 0.05 | 1/16 | 0.76 | 1.44 | 5/8 | 0.66 | 1 | 5/16 | 11/16 | 0.43 |
| 6-RUD-2 | -600-6-2 | 6RU2 | 3/8 | 0.50 | 0.09 | 1/8 | 0.76 | 1.61 | 5/8 | 0.66 | 1.06 | 7/16 | 11/16 | 0.6 |
| 6-RUD-4 | -600-6-4 | 6RU4 | 3/8 | 0.60 | 0.19 | 1/4 | 0.76 | 1.70 | 5/8 | 0.66 | 1.12 | 9/16 | 11/16 | 0.7 |
| 6-RUD-5 | -600-6-5 | 6RU5 | 3/8 | 0.64 | 0.25 | 5/16 | 0.76 | 1.74 | 5/8 | 0.66 | 1.16 | 5/8 | 11/16 | 0.73 |
| 8-RUD-2 | -810-6-2 | 8RU2 | 1/2 | 0.50 | 0.09 | 1/8 | 0.86 | 1.78 | 7/8 | 0.90 | 1.12 | 7/16 | 7/8 | 0.6 |
| 8-RUD-4 | -810-6-4 | 8RU4 | 1/2 | 0.60 | 0.19 | 1/4 | 0.86 | 1.85 | 7/8 | 0.90 | 1.16 | 9/16 | 718 | 0.7 |
| 8-RUD-6 | -810-6-6 | 8RU6 | 1/2 | 0.66 | 0.28 | 3/8 | 0.86 | 1.91 | 7/8 | 0.90 | 1.22 | 11/16 | 7/8 | 0.76 |
| 10-RUD-6 | -1010-6-6 | 10RU6 | 5/8 | 0.66 | 0.28 | 3/8 | 0.86 | 1.94 | 1 | 0.96 | 1.25 | 11/16 | 1 | 0.76 |
| 10-RUD-8 | -1010-6-8 | 10RU8 | 5/8 | 0.90 | 0.41 | 1/2 | 0.86 | 2.05 | 1 | 0.96 | 1.25 | 7/8 | 1 | 0.86 |
| 12-RUD-4 | -1210-6-4 | 12RU4 | 3/4 | 0.60 | 0.19 | 1/4 | 0.86 | 1.94 | 1-1/8 | 0.96 | 1.25 | 9/16 | 1-1/8 | 0.7 |
| 12-RUD-6 | -1210-6-6 | 12RU6 | 3/4 | 0.66 | 0.28 | 3/8 | 0.86 | 2.00 | 1-1/8 | 0.96 | 1.31 | 11/16 | 1-1/8 | 0.76 |
| 12-RUD-8 | -1210-6-8 | 12RU8 | 3/4 | 0.90 | 0.41 | 1/2 | 0.86 | 2.11 | 1-1/8 | 0.96 | 1.31 | 7/8 | 1-1/8 | 0.86 |
| 12-RUD-10 | -1210-6-10 | 12RU10 | 3/4 | 0.96 | 0.50 | 5/8 | 0.86 | 2.11 | 1-1/8 | 0.96 | 1.31 | 1 | 1-1/8 | 0.86 |
| 16-RUD-8 | -1610-6-8 | 16RU8 | 1 | 0.90 | 0.41 | 1/2 | 1.04 | 2.38 | 1-1/2 | 1.23 | 1.5 | 7/8 | 1-1/2 | 0.86 |
| 16-RUD-12 | -1610-6-12 | 16RU12 | 1 | 0.96 | 0.62 | 3/4 | 1.04 | 2.38 | 1-1/2 | 1.23 | 1.5 | 1-1/8 | 1-1/2 | 0.86 |
Material of Construction
| Monel | Monel 400, Monel K500, Monel R-405 |
| Nickel | Nickel 200, Nickel 201 |
| Inconel | Inconel 600, Inconel 601, Inconel 625, Inconel 718 |
| Incoloy | Incoloy 800, Inconel 800H, 800HT |
| Hastalloy | Hastalloy B2, Hastalloy B3, Hastalloy C22, Hastalloy C276, Hastalloy X |
| Titanium | Gr1, Gr2, Gr3, Gr5, Gr7, Gr11 |
| Stainless Steel | ASME / ASTM SA / A403 SA / A 774 WP-S, WP-W, WP-WX, 304, 304L, 316, 316L, 304/304L, 304H, 316H, 316/316L, 321, 330, 347, 309/S, 310/S, 317/L, 333, 410/S, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404 |
| Carbon Steel | ASTM A 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70 |
| Duplex Steel | ASTM / ASME A/SA 182 UNS F44, F45, F51, F53, F55, F60, F61 |
| Alloy Steel | ASTM SA 182 – E25, E26, E27, E28, E29B, E30B, E39B, E40B, E36B, E36C, E41B, AISI4130, AISI4140, AISI4340, 42CRMO4, 16MNCR5, 20MNCR5, 21CrMoV57, EN353, EN354, F11, F22, F91, F9, P11, P22, P91, P9, P5, P92, EN42J, EN8, EN19 |
 |
 |
Reducing Union
| Imperial Tubing | |||||||||||||||||
| Tube O.D | A | C1 | C2 | D | W inch | Min bore | |||||||||||
| 1 inch | 2 inch | mm | inch | mm | inch | mm | inch | mm | inch | mm | |||||||
| 1/8 | 1/16 | 1.20 | 30.5 | 0.60 | 15.2 | 0.43 | 10.9 | 0.81 | 20.6 | 7/16 | 0.05 | 1.3 | |||||
| 3/16 | 1/16 | 1.25 | 31.8 | 0.63 | 16.0 | 0.43 | 10.9 | 0.86 | 21.8 | 7/16 | 0.05 | 1.3 | |||||
| 3/16 | 1/8 | 1.42 | 36.1 | 0.63 | 16.0 | 0.60 | 15.2 | 0.92 | 23.4 | 7/16 | 0.09 | 2.3 | |||||
| 1/4 | 1/16 | 1.35 | 34.3 | 0.70 | 17.8 | 0.43 | 10.9 | 0.91 | 23.1 | 1/2 | 0.05 | 1.3 | |||||
| 1/4 | 1/8 | 1.52 | 38.6 | 0.70 | 17.8 | 0.60 | 15.2 | 0.97 | 24.6 | 1/2 | 0.09 | 2.3 | |||||
| 1/4 | 3/16 | 1.54 | 39.1 | 0.70 | 17.8 | 0.63 | 16.0 | 1.00 | 25.4 | 1/2 | 0.13 | 3.3 | |||||
| 5/16 | 1/4 | 1.67 | 42.4 | 0.73 | 18.6 | 0.70 | 17.8 | 1.08 | 27.4 | 9/16 | 0.19 | 4.8 | |||||
| 3/8 | 1/16 | 1.44 | 36.6 | 0.76 | 19.3 | 0.43 | 10.9 | 1.00 | 25.4 | 5/8 | 0.05 | 1.3 | |||||
| 3/8 | 1/8 | 1.60 | 40.6 | 0.76 | 19.3 | 0.60 | 15.2 | 1.06 | 26.9 | 5/8 | 0.09 | 2.3 | |||||
| 3/8 | 1/4 | 1.72 | 43.7 | 0.76 | 19.3 | 0.70 | 17.8 | 1.13 | 28.7 | 5/8 | 0.19 | 4.8 | |||||
| 3/8 | 5/16 | 1.75 | 44.5 | 0.76 | 19.3 | 0.73 | 18.6 | 1.16 | 29.5 | 5/8 | 0.25 | 6.4 | |||||
| 1/2 | 1/8 | 1.72 | 43.7 | 0.86 | 21.8 | 0.60 | 15.2 | 1.09 | 27.7 | 13/16 | 0.09 | 2.3 | |||||
| 12/ | 1/4 | 1.84 | 46.7 | 0.86 | 21.8 | 0.70 | 17.8 | 1.16 | 29.5 | 13/16 | 0.19 | 4.8 | |||||
| 1/2 | 3/8 | 1.90 | 48.3 | 0.86 | 21.8 | 0.76 | 19.3 | 1.22 | 31.0 | 13/16 | 0.28 | 7.1 | |||||
| 5/8 | 3/8 | 1.93 | 49.0 | 0.86 | 21.8 | 0.76 | 19.3 | 1.25 | 31.8 | 15/16 | 0.28 | 7.1 | |||||
| 5/8 | 1/2 | 2.02 | 51.3 | 0.86 | 21.8 | 0.86 | 21.8 | 1.25 | 31.8 | 15/16 | 0.41 | 10.4 | |||||
| 3/4 | 1/2 | 2.08 | 52.8 | 0.86 | 21.8 | 0.86 | 21.8 | 1.31 | 33.3 | 1.1/16 | 0.41 | 10.4 | |||||
| 3/4 | 5/8 | 2.08 | 52.8 | 0.86 | 21.8 | 0.86 | 21.8 | 1.31 | 33.3 | 1.1/16 | 0.50 | 12.7 | |||||
| 1 | 3/4 | 2.35 | 59.7 | 1.04 | 26.4 | 0.86 | 21.8 | 1.50 | 38.1 | 1.3/8 | 0.63 | 16.0 | |||||
|
Metric tubing |
|||||||||||||||||
| Tube O.D 1 mm 2 mm |
A mm |
C1
mm |
D mm |
W mm |
Min bore mm |
||||||||||||
| 6 | 3 | 38.7 | 17.7 | 15.3 | 1/2 | 2.4 | |||||||||||
| 8 | 6 | 42.4 | 18.6 | 27.4 | 9/16 | 4.8 | |||||||||||
| 10 | 6 | 44.5 | 19.5 | 29.4 | 11/16 | 4.8 | |||||||||||
| 10 | 8 | 44.5 | 19.5 | 29.4 | 11/16 | 6.4 | |||||||||||
| 12 | 6 | 47 | 22 | 29.4 | 13/16 | 4.8 | |||||||||||
| 12 | 8 | 47.8 | 22 | 30.2 | 13/16 | 6.4 | |||||||||||
| 12 | 10 | 48.7 | 22 | 31 | 13/16 | 7.9 | |||||||||||
| 16 | 12 | 52 | 22 | 31.8 | 15/16 | 9.5 | |||||||||||
| 25 | 18 | 60.5 | 26.5 | 38.1 | 1.3/8 | 15.1 | |||||||||||
| 25 | 20 | 62.3 | 26.5 | 39.9 | 1.3/8 | 15.9 | |||||||||||
Price List of Reducing Union
Jaydeep Steels is one of the most competitive suppliers of pipes and tubes from India. Our prices for Union Cross are very competitive. Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Jaydeep Steels maintains a stock of all standard items and can export them at the best price for Reducing Union.
Reducing Union - Industries & Applications
Our Reducing Union is used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Available Stock of Reducing Union
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Reducing Union.
How to Buy Reducing Union
Jaydeep Steels is a leading stockist, distributor, and supplier of Reducing Union from India. We maintain huge stocks and you can easily buy Reducing Union and other forms of Pipe Fittings at one of the best prices. Please use the contact button or click here to send us your requirement to Buy Union Cross from Jaydeep Steels.
